DAHUA 32Ch Dvr
DAHUA 32Ch Dvr 2Hdd Upto 5Mp
DAHUA 32Ch Dvr 2Hdd Upto 5Mp
DAHUA 32Ch Dvr 2Hdd Upto 5Mp

DAHUA 32Ch Dvr 2Hdd Upto 5Mp

DAHUA
R 5,499
Estimated delivery 2–4 working days
Out of stock
FREE NATIONWIDE DELIVERY
on orders over R 500
Quantity
Out of stock
  • Interest Free Payments available
  • Hassle Free Returns within 7 days
  • 6-month limited warranty
Price: R 5,499

Description

> Max 32 channels IP camera inputs; Max 128Mbps Incoming Bandwidth. Manual, Schedule (Regular, Continuous), MD (Video detection: Motion Detection, Video Loss, Tampering), Alarm, Stop.

Key features

  • > Support HDCVI/AHD/TVI/CVBS/IP video inputs
  • > Long transmission distance over coax cable
  • > Support 2 SATA HDD, up to 16TB
  • Embedded LINUX
  • Pal/ntsc
  • Two-way Talk
  • Reuse audio in/out, RCA
  • Recording
  • Compression
  • 4M-N, 1080P, 1080N, 720P, 960H, D1, HD1, bcif, CIF, qcif
  • Record Rate
  • Bit Rate
  • Record Mode
  • Record Interval
  • 1 ~ 60 min (default: 60 min), Pre-record: 1 ~ 30 sec, Post-record: 10 ~ 300 sec
  • OSD
  • Camera title, Time, Video loss, Camera lock, Motion detection, Recording
  • HTTP, TCP/IP, IPv4/IPv6, UPnP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPoE,DDNS, FTP, Alarm Server, P2P,IP Search (Support Dahua IP camera, DVR, NVS, etc.)
  • Max. User Access
  • Smart Phone
  • iPhone, iPad, Android
  • Interoperability
  • Trigger Events
  • Recording, PTZ, Tour, Video Push, Email, FTP, Snapshot, Buzzer and Screen Tips
  • Motion Detection, MD Zones: 396 (22 `d7 18), Video Loss, Tampering and Diagnosis
  • N/A
  • Playback and Backup
  • Playback
  • Search Mode
  • Time /Date, Alarm, MD and Exact Search (accurate to second)
  • Playback Function
  • Play, Pause, Stop, Rewind, Fast play, Slow Play, Next File, Previous File, Next Camera, Previous Camera, Full Screen, Repeat, Shuffle, Backup Selection, Digital Zoom
  • Backup Mode
  • Internal HDD
  • eSATA
  • Electrical
  • Construction
  • Installation
  • Desktop installation
  • 10`b0C ~ +55`b0C (+14`b0F ~ +131`b0F), 0~ 90% RH
  • 20`b0C ~ +70`b0C (-4`b0F ~ +158`b0F) , 0~ 90% RH

Specifications

  • 32 Channel Penta-brid 1080P Digital Video Recorder
  • > H.264+/H.264 dual-stream video compression
  • 32 Channel, BNC
  • 4MP, 1080P@25/30fps, 720P@50/60fps, 720P@25/30fps
  • 4MP, 1080P@25/30, 720P@25/30fps
  • 32 Channel, each channel up to 5MP
  • 1/1, RCA
  • H.264+/H.264
  • Resolution
  • Main stream: 4M-N/1080P(1~15fps); 1080N/720P/960H/D1/HD1/BCIF/CIF/QCIF (1~25/30fps)
  • Sub steram: D1/CIF/QCIF(1~15fps)
  • 1Kbps ~ 6144Kbps Per Channel
  • 1 hdmi, 1 VGA, 1 TV
  • 1920`d71080, 1280`d71024, 1280`d7720, 1024`d7768
  • 1/4/8/9/16/25/36
  • 1 RJ-45 Port (1000M)
  • 128 users
  • ONVIF 2.42, CGI Conformant
  • 1/4/9/16
  • 2 SATA Port, up to 8TB capacity
  • 1 USB 2.0 , 1 USB 3.0
  • RS232
  • RS485
  • 1 Port, for PTZ Control
  • Dc12v/5a
  • <20W (Without HDD)
  • 1U, 375mm'd7287mm'd753mm (14.8" x 11.3" x 2.1")
  • 2.35kg (5.2 lb) (without HDD)
  • 3.2kg (7.05lb)

Frequently Bought Together Frequently bought

Product Information

Categories Dahua / Security & Surveillance
Brand Dahua
Channels 32 Channel Penta-brid
Resolution Up to 5MP (IP), 4MP/1080P (HDCVI/AHD/TVI)
Compression H.264+/H.264
Operating System Embedded Linux
IP Bandwidth 128 Mbps
Audio 1 In / 1 Out RCA
Display Outputs 1 HDMI, 1 VGA, 1 TV
Network 1 RJ-45 (1000M)
Storage 2 SATA HDD, up to 16TB
USB 1x USB 2.0, 1x USB 3.0
Power Supply DC 12V / 5A
Power Consumption <20W (without HDD)
Dimensions 375 x 287 x 53 mm
Weight 2.35 kg (without HDD)
Barcode 6923172531469
