HIKVISION 16Ch 10…
HIKVISION 16Ch 1080P 4Mp Dvr
HIKVISION 16Ch 1080P 4Mp Dvr
HIKVISION 16Ch 1080P 4Mp Dvr
HIKVISION 16Ch 1080P 4Mp Dvr

HIKVISION 16Ch 1080P 4Mp Dvr

HIKVISION
R 2,299
Estimated delivery 2–4 working days
Out of stock
FREE NATIONWIDE DELIVERY
on orders over R 500
Quantity
Out of stock
  • Interest Free Payments available
  • Hassle Free Returns within 7 days
  • 6-month limited warranty
Price: R 2,299

Description

Analog and HD-TVI video input: 16-ch,BNC interface (1.0Vp-p, 75 `d9)connection. Supported camera types: 3 MP, 1080p25, 1080p30, 720p25, 720p30, 720p50, 720p60.

Key features

  • Note: The 3 MP signal input is only available for channel 1 of DS-7104HQHI-K1, channel 1/2 of
  • DS-7108HQHI-K1, and channel 1/2/3/4 of DS-7116HQHI-K1.
  • Two-way Audio: 1-ch, RCA (2.0 Vp-p, 1 K'd9) (using audio input)
  • HDMI/VGA Output: 1920 `d7 1080 / 60 Hz,1280 `d7 1024 / 60 Hz, 1280 `d7 720 / 60 Hz, 1024 `d7 768 / 60 Hz
  • Recording resolution: When 1080p Lite mode not enabled: 3 MP/1080p/720p/VGA/WD1/4CIF/CIF;
  • Network protocols: TCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP™, HTTPS, ONVIF
  • Network Interface: 1; 10M / 100M self-adaptive Ethernet interface
  • Working Temperature: -10 °C ~+55 °C (14 °F ~ 131 °F)

Specifications

  • Ds-7116hqhi-k1 UP TO 4MP H.265
  • DS-7116HQHI-K1 - Product Discription
  • Model DS-7116HQHI-K1
  • Audio Input: 1-ch
  • Video Compression: H.265+/H.265/H.264+/H.264
  • Support AHD input: 1080p/25Hz, 1080p/30Hz, 720p/25Hz, 720p/30Hz
  • Support CVI input: 1080p/25Hz, 1080p/30Hz, 720p/25Hz, 720p/30Hz
  • Video Input Interface: BNC (1.0 Vp-p, 75`d9)
  • Audio Compression: G.711u
  • Audio Input Interface: RCA (2.0 Vp-p, 1 k'd9)
  • When 1080p Lite mode enabled: 3 MP/1080p lite/720p/VGA/WD1/4CIF/CIF
  • Frame Rate: Main stream:
  • For 3 MP stream access: 3 MP/1080p/720p/VGA/WD1/4CIF/CIF@15fps
  • For 1080p stream access: 1080p/720p@15fps; VGA/WD1/4CIF/CIF@25fps (P)/30fps (N)
  • For 720p stream access: 720p/VGA/WD1/4CIF/CIF@25fps (P)/30fps (N)
  • 3 MP@15fps
  • 1080p lite/720p lite/VGA/WD1/4CIF/CIF@25fps (P)/30fps (N)
  • Video Bit Rate: 32 Kbps-6 Mbps
  • Stream Type: Video/Video&Audio
  • Audio Output: 1-ch RCA(Linear, 1k'd9)
  • Audio Bit Rate: 64kbps
  • Dual Stream: Support
  • Playback Resolution: 3 MP/1080p/720p/VGA/WD1/4CIF/CIF
  • Synchronous Playback: 16-ch
  • Remote connections: 128
  • Interface Type: 1 SATA Interface
  • Capacity: Up to 6 TB capacity for each disk
  • USB Interface: 2 USB 2.0 Interfaces
  • Power Supply: 12V DC
  • Consumption: ≤ 15 W(without hard disks)
  • Working Humidity: 10% ~ 90%
  • Chassis: Mini 1U chassis
  • Dimensions: 285 `d7 210 `d7 45 mm
  • (11.2`d7 8.3 `d7 1.8 inch)
  • Weight: ≤ 1 kg (2.2 lb)

Frequently Bought Together Frequently bought

Product Information

Categories Hikvision / Hikvision DVRs / Security & Surveillance
Brand Hikvision
Model DS-7116HQHI-K1
Channels 16-ch
Video Compression H.265+/H.265/H.264+/H.264
Supported Cameras Up to 4 MP
Audio Compression G.711u
HDMI/VGA Output 1920 x 1080 / 60Hz
Video Bit Rate 32 Kbps - 6 Mbps
Audio Bit Rate 64 kbps
Remote Connections 128
Storage 1 SATA, up to 6 TB per disk
Network Interface 10M/100M self-adaptive Ethernet
USB 2 x USB 2.0
Power Supply 12V DC
Power Consumption <= 15 W (without HDD)
Form Factor Mini 1U chassis
Dimensions 285 x 210 x 45 mm
Weight <= 1 kg
Barcode 6954273648787
