HIKVISION 16Ch 4K Nvr 160Mbps No Poe

Up to 2-ch@8 MP or 4-ch@4 MP or 8-ch@1080p decoding capacity. 1 HDMI and 1 VGA interfaces, both interfaces support independent video output.

Key features

• 2 HDD CAN take 2 MP cameras ds-7616ni-k2
• 2 SATA interfaces for HDD connection (up to 10 TB capacity per HDD)
• Incoming Bandwidth
• Outgoing Bandwidth
• 4K (3840 `d7 2160)/30 Hz, 2K (2560 `d7 1440)/60 Hz, 1920 `d7 1080/60 Hz, 1600 `d7 1200/60 Hz, 1280 `d7 1024/60 Hz, 1280 `d7 720/60 Hz
• 1920 `d7 1080/60 Hz, 1280 `d7 1024/60 Hz, 1280 `d7 720/60 Hz
• 1-ch, RCA (2.0 Vp-p, 1k'd9, using the audio input)
• Decoding
• Decoding Format
• Recording Resolution
• Synchronous Playback
• Decoding Capability
• 1-ch@12 MP (30 fps)/2-ch@8 MP (30 fps)/4-ch@4 MP (30 fps)/8-ch@1080p (30 fps)
• Stream Type
• Remote Connection
• Tcp/ip, dhcp, ipv4, ipv6, DNS, ddns, NTP, rtsp, sadp, smtp, snmp, NFS, iscsi, isup, upnp™, http, https
• Sata
• Up to 10 TB capacity for each HDD
• Front panel: 1 `d7 USB 2.0; Rear panel: 1 `d7 USB 2.0
• Alarm In/Out
• Consumption
• Working Temperature
• 10 `b0C to 55 `b0C (14 `b0F to 131 `b0F)
• Working Humidity
• 385 `d7 315`d7 52 mm (15.2" `d7 12.4" `d7 2.0")
• FCC
• CE
• EN 55032: 2015, EN 61000-3-2, EN 61000-3-3, EN 50130-4, EN 55035: 2017

Specifications

• 16-ch 1U 4K NVR
• Up to 16-ch IP camera inputs
• H.265+/H.265/H.264+/H.264 video formats
• Up to 160 Mbps incoming bandwidth
• 16-ch
• 160 Mbps
• 1-ch, RCA (2.0 Vp-p, 1 K'd9)
• 1-ch, RCA (Linear, 1 K'd9)
• H.265/h.265+/h.264/h.264+
• 12 MP/8 MP/6 MP/5 MP/4 MP/3 mp/1080p/uxga/720p/vga/4cif/dcif/2cif/cif/qcif
• G.711ulaw/G.711alaw/G.722/G.726
• 128-ch
• 1, RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface
• 2 SATA interfaces
• Capacity
• 4/1
• 12 VDC, 3.33A
• ≤ 15 W (without HDD)
• 10 to 90 %
• Dimension (W `d7 D `d7 H)
• ≤ 1 kg (without HDD, 2.2 lb.)
• Part 15 Subpart B, ANSI C63.4-2014
