HIKVISION Smart Conference Camera

Integrated design, plug and play, camera, microphone, and speaker all in one to meet the needs of video conference. Ultra high definition 4K camera provides high-definition meeting pictures.

Key features

• AI applications such as automatic framing and speaker tracking contribute to efficient meetings.
• Array microphone and high-fidelity speakers for ultimate audio experience.
• Supports HDR, intelligently adjusting video settings in all lighting conditions, to capture the best image of everyone on camera.
• Good compatibility, suitable for mainstream cloud conference platforms.
• Automatic privacy cover to meet the privacy requirements of user meeting rooms.
• Built-in 8-array microphones, 6-meter sound collection, meeting the needs of small and medium-sized conference rooms.
• Image Sensor
• Max. Resolution
• MJPEG: 4K@30 fps (USB3.0), 1080P@30 fps (USB2.0) H.264: 4K@30 fps
• Shutter Time
• Preset
• Digital Zoom
• Focal Length & FOV
• Microphone
• Type
• Pickup Distance
• Amount
• SNR
• AEC, ANS, AGC
• Sampling Rate
• Functions
• LED Indicator
• Smart Auto Frame
• The camera adjuts the best view angle accordin to the participants number of the conference.
• Smart Speaker Tracking
• The camera automatically trackes and focuses on the speaker during the conference.
• Image
• Image Enhancement
• BLC
• Privacy Mask
• electric privacy mask
• White Balance
• Auto white balance mode, daylight mode, natural light mode, warm light mode, sodium lamp mode, lock white balance mode
• Packing List
• 1 x QR code paper card for User Manual `d7 1
• Bluetooth
• Support audio bluetooth and remote control bluetooth

Specifications

• Ids-uvc-x28
• 1/2.8” progressive scan CMOS
• 10 us ~ 33333 us
• Supports 5 preset positions
• 3 `d7 digital zoom
• Lens
• Focal Length:2.02mm
• Diagonal FOV'a3°118.8`b0
• Horizontal FOV:109.9`b0
• Vertical FOV:74.6`b0
• Aperture
• f/2.5
• 360`b0 Omni-direction
• In the radius up to 6m
• 8
• ≥ 60 db
• 3A Algorithm
• 48 KHz
• Effective Bandwidth (-10 dB)
• 150hz-18khz
• White: Normally working
• Red: Standby
• 10W Hi-Fi Speaker
• 10W
• 1 x hdmi OUT
• 1 x RJ45 1000BASE-T (network interface reserved)
• 1 `d7 USB 3.0, type-C interface
• 1 `d7 MIC USB
• 1 x Power interface
• DC 12v'b15%, MAX 12.06W
• 616 `d7 145 `d7104.23mm
• Operating Temperature:0 `b0C - 40 `b0C;Operating Humidity:10% - 90%
• 727x 227 x 213mm
• ≈5.360KG
• 1 x Smart Conference Camera;
• 1 x Power Adpter
• 1 x Remote control
• 2 x AAA Battery
• 1 x 2m USB Type-C cable
• 1 x NFC Sticker
• 1 x Desk mouting bracket
• 1 x Screw Pack
• 4K@30fps
• 4K@30fps, 1080p@60fps, 720p@60fps
