HISENSE 55" Uhd Smart Led Dolby Vision

USB interface type 2.0 (Qty / List `85.) 2/ USB2. Wi-Fi protocols IEEE 802.11 {b, g, n, ac, ad, ..} a, b, g, n, ac.

Key features

• HDR UHD AI upscaler DTS virtualx
• UHD AI upscaler
• Precision colour
• Dolby Vision
• DTS virtual X
• Sports Mode
• Product
• Factory Qingdao
• Document
• Circulation Restricted, internal use only
• Status Confirmed
• Issued by Al
• Panel manufacturer Hisense
• Display technology LCD/ LED lit
• Backlight source Direct LED
• Screen curvature radius -
• Quantum dot No
• Wide colour gamut No
• KSF phosphor No
• UHD Premium No
• USB interface type 3.0 (Qty / List`85.) 0
• HDMI type 4K@60Hz with HDCP version 2.2 YES
• Enhanced Audio Return Channel ( eARC) No
• CEC- Consumer Electronics Control via HDMI Yes
• Smart TV
• DLNA compliance Yes
• Anyview (Screen mirroring) Yes
• Catch-up TV services Iview, SBS on Demand, 7 Plus, 9 Jumpin
• (Tenplay available from Playsore)
• Web browser [Chrome | Opera | Other] Odin
• Digital TV reception
• Television system (DVB-T / DVB-T2) Yes / Yes
• Video decoder (MPEG2 / MPEG 4) Yes / Yes
• LCN- Logical channel number and DTV Service name support Yes
• Teletext / Teletext signal interruption (TAB compliant) / 16 : 9 TLTX Yes / Yes / Yes
• Subtitles Yes
• RF Signal strength indicator Yes
• RF Signal quality indicator Yes
• RF Bit error rate indicator Yes
• EPG- Electronic programming guide, 7 days for all services Yes
• Audio description (vision impairment aid) Yes
• Parental rating lock Yes
• Analogue TV reception
• Teletext / Teletext signal interruption (TAB compliant) / 16 : 9 TLTX No/ No/ No
• Image processing
• Backlight control No
• Light sensing No
• Dynamic backlight control No
• Frame rate control No
• Variable Refresh Rate (VRR) No
• FreeSync No
• Auto Low Latency Mode for VRR Yes
• Local dimming/ controllable zones No
• Movie Zoom/ Direct
• HDR - High Dynamic Range for luminance (DMP / Netflix / HDMI) No / No / No
• HDR system (HDR10 / HDR10+ / Dolby Vision) Yes/ No / YES
• HLG (Hybrid Log-Gamma) for HDR YES
• Dual image (PIP / POP) No/ No
• Motion enhancement and compensation (MEMC) No
• Sound
• Number of speakers (Tweeter / Midrange / Woofer) 2 /0 /0
• Automatic volume level (AVL) Yes
• Dolby Digital Yes
• Audio enhancement -Type {SRS, BBE, SAP, DBX-TV`85.} DTS Virtual X
• Lip-sync adjustment Yes
• On/off timer Yes
• Sleep timer Yes
• Program lock Yes
• OSD transparency control Yes
• Software version OSD indication Yes
• Legal requirements: Disclaimer / Acceptance of Terms Yes / Yes
• Favourite channels list Yes
• Electronic point of sales (E-POS) Yes
• OTA- Over the air software updates Yes
• Voice command Yes
• Screen mirroring {Miracast, Anyview Cast, ...} Anyview Cast
• Smartphone remote control application {Rremote Now, ...} Yes
• Replaceable demo video for Store mode Yes
• Remote control via serial port No
• Personal Video Recorder Yes
• Time Shift Yes
• DTV Recording (EPG scheduling / start from Standby ) Yes / Yes
• DivX decoder No
• MPEG4 (H.264) / H.265 decoder Yes / Yes
• DMP- Digital media player content (Music / Video / Photos / Text) Yes / Yes / Yes / No
• DMP Auto-play No
• DMP for UHD content via USB Yes
• DMP File allocation table (FAT / FAT32 / exFAT / NTFS) Yes / Yes / No / Yes
• PVR File allocation table (FAT / FAT32 / exFAT / NTFS) Yes / Yes / No / Yes
• Hotel lock
• Protected Hotel lock submenu (Password / fixed code) No / Yes
• Clone function for programs, sound and image settings. Yes
• Sub-menu lock, including tuning lock Yes
• Keyboard lock Yes
• Maximum volume lock Yes
• Power on mode (On / Standby / Last) Yes / Yes / Yes
• Inputs access (Enable / Disable) Yes
• Hardware
• Dual Tuner No
• Colour (Front bezel, rear, stand) Black / Black / Black
• Speakers mounted in enclosure Yes
• Mains power switch No
• Swivel base No
• Compact packaging Yes
• Supply range [Voltage / Frequency ] 100 ~ 240V'a3`ac50Hz/60Hz
• Maximum time delay Power On to sound an image 30sec
• Installation
• Wall mount dimensions (Horiz x Vert) 200`d7300 mm
• VESA compliance Yes
• Detachable power cord Yes
• Remote controller (Technology / Part number ) IR /EN2AC30H(0011)
• User manual (Available online) / Quick setup guide (Print) 1 / 1
• Warranty [In User manual | In separate sheet] In separate sheet
• Skype camera (Qty / Part number) -
• 3D glasses type [Passive | Shutter] / Link [RF | IR | BT] -
• Carton box dimensions (W x H x D) 1364`d7136`d7864mm
• Container load (20ft / 40ft / 40ft HC) 142/288/432
• EMC- Electromagnetic Compatibility Yes
• CB- Electrical safety Yes
• HDMI Yes (Hisense internal test)
• MEPS- Test report No
• ROHS No
• Electrical safety conformity for Australia Yes
• Documentation
• Panel specifications Yes
• Initial specifications (input form) Yes
• Confirmed product specifications Yes
• List of DMP formats for audio and video Yes (QSG)
• CB report and certificate Yes
• EMC report and certificate Yes

Specifications

• Hisense 55A6H UHD 4K TV
• Factory model 55A53FXVT
• Description 139cm (55" ) Direct LED Television
• Specifications form version HA220120
• Revision number 1
• Date 1/27/2022
• Panel model LCM:HD550Y1U51-T0LA, Open Cell :T550QVN10.0
• Active display area, horizontal dimension 1209.6mm
• Active display area, vertical dimension 680.4mm
• Screen size (rounded to nearest integer) 139cm
• Screen size (rounded to nearest integer) 55inch
• Resolution (Horiz x Vert) 3840X2160
• Colour depth 8bit+FRC
• Image refresh frequency 60Hz
• Smooth motion rate 60
• 3D image -
• Typical brightness of white 300cd/m2
• Native contrast ratio 4000 : 1
• Viewing Angle (Horiz / Vert) 178/ 178Degrees
• Response Time 8ms
• RF- Radio frequency input 1
• AV input 1
• AV output 0
• Optical digital audio output (SPDIF) 1
• Earphone jack 1
• HDMI inputs 3
• HDMI type 8K@60Hz No
• HDMI 2.1 compliant input No
• Ethernet port (RJ45 connector) 1
• Wi-Fi bands 2.4/5.0GHz
• Bluetooth / BT version Yes / 5.0
• UHD (4k) streaming Yes
• Installed Applications {List `85`85} Netflix/Youtube/Prime Video`85`85
• Freeview Plus - HbbTV 2.0 Yes
• AC3 Surround sound decoder Yes
• AS 4599.1 compliance Yes
• AS 4933.1 compliance Yes
• Colour-Sound systems in VHF band PALSECAM, B/G, D/K, I
• Colour-Sound systems in UHF band PALSECAM, B/G, D/K, I
• Stereo sound decoder {A2, Nicam, `85.} No
• Zoom function settings Automatic/ 16:9/ 4:3/ Panoramic/
• 1:1 Pixel mapping No
• HEVC (H.265) decoder Yes
• Audio power output per channel 8Watt
• Power off if no signal Yes
• User interface VIDAA U5
• Power on, apply default sound/image settings No
• Power on source selection Yes
• Power on RF channel selection Yes
• Processor / Cores MT9602EAATBA / 4
• Standby consumption < 0.5W
• Stand area (Width / Depth) 1031`d7291 mm
• Wall mount, screw thread M6/10mm
• Power cord length 155cm
• Battery (size / quantity) AAA / 2
• 3D glasses (Qty / Part number) -
• Dimensions with stand (W x H x D) 1232`d7773`d7291mm
• Dimensions without stand (W x H x D) 1232`d7711`d774mm
• Net weight (with stand / without stand) 11.5Kg/11.3Kg
• Gross weight 17.5 Kg
• Power cord, plug and connector Australian safety approval Yes
