TPLINK 8Port (4Port Poe) Switch

Network Media 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m). Dimensions ( W x D x H ) 6.7*3.9*1.1 in. (171*98*27 mm).

Key features

• AUTO Negotiation/AUTO MDI/MDIX
• 100BASE-TX: UTP category 5, 5e cable (maximum 100m)
• Fan Quantity Fanless
• External Power Supply External Power Adapter(Output: 48VDC / 1.25A)
• Transmission Method Store-And-Forward
• Advanced Functions Compatible With IEEE 802.3af Compliant PDs
• Priority Function
• Mac Address Auto-Learning And Auto-Aging
• IEEE802.3x Flow Control For Full-Duplex Mode And Backpressure For Half-Duplex Mode
• Others
• Consumption 2.3 watts (max. no PD connected)
• 59.3 watts (max. with 57w PD connected)

Specifications

• Interface 8 10/100Mbps RJ45 Ports
• EIA/TIA-568 100`d9 STP (maximum 100m)
• Power Consumption Maximum (PoE on): 60.2W (220V/50Hz)
• Maximum (PoE off): 3.2W (220V/50Hz)
• PoE Ports (RJ45) Standard: 802.3 af compliant
• PoE Ports: Port1- Port4
• Power Supply: 57W
• Backbound Bandwidth 1.6Gbps
• Mac Address Table 2K
• Package Contents TL-SF1008P, Power Adapter, User Guide
• Environment Operating Temperature: 0℃~40℃ (32℉~104℉)
• Storage Temperature: -40℃~70℃ (-40℉~158℉)
• Operating Humidity: 10%~90% non-condensing
• Storage Humidity: 5%~90% non-condensing
