VIEWSONIC 23.6" Tft Active Matrix Type

On Screen Display: Auto Image Adjust, Contrast/Brightness, Input Select, Audio Adjust, Color Adjust, Information, Manual Image Adjust, Setup Menu, Memory Recall. Regulations: cTUVus, FCC-B, ICES003, Energy Star, EPEAT, CEC, MX-CoC, Mexico Energy, CE, CE EMC, CB, RoHS, ErP, REACH, WEEE, EAC, UkrSEPRO, RCM, GEMS, VCCI, PSE, BIS.

Key features

• LCD Touch Monitor
• Finger, stylus, and glove touch compatible
• Magnetic pen placeholder
• Pixel Size: 0.272 mm (H) x 0.272 mm (V)
• Compatibility
• Additional Hardware
• Controls
• Wall Mount
• Digital Sync: TMDS - DVI-D, TMDS - HDMI (v1.4)
• PACKAGE CONTENTS: TD2423 x1, 3-pin Plug (IEC C13 / CEE22) x1, HDMI Cable (v1.4; Male-Male) x1, USB A/B Cable (v2.0; Male-Male) x1, Audio Cable (Male-Male) x1, Quick Start Guide x1
• Recycle/Disposal: Please dispose of in accordance with local, state or federal laws.

Specifications

• 24” IR Touch Monitor
• Intuitive 10-point touchscreen
• Adjustable back tilt up to 40-degrees
• Scratch-resistant 7H hardness screen
• Display Size (in.): 24
• Viewable Area (in.): 23.6
• Panel Type: VA Technology
• Resolution: 1920 x 1080
• Resolution Type: FHD (Full HD)
• Static Contrast Ratio: 3,000:1 (typ)
• Dynamic Contrast Ratio: 20M:1
• Light Source: LED
• Brightness: 250 cd/m'b2 (typ)
• Colors: 16.7M
• Color Space Support: 8 bit (6 bit + Hi-FRC)
• Aspect Ratio: 16:9
• Response Time (Typical GTG): 7ms
• Response Time (GTG w/OD): 7ms
• Response Time (Typical Tr+Tf): 25ms
• Viewing Angles: 178° horizontal, 178° vertical
• Backlight Life (Hours): 40000 Hrs (Min)
• Curvature: Flat
• Refresh Rate (Hz): 75
• Low Blue Light: Software solution
• Flicker-Free: Yes
• Color Gamut: NTSC: 72% size (Typ)
• sRGB: 104% size (Typ)
• Touch Screen: IR, 10-point multi-touch
• Surface Treatment: Glossy, Hard Coating (7H)
• Cover Glass Thickness: 1.85mm
• PC Resolution (max): 1920x1080
• Mac® Resolution (max): 1920x1080
• PC Operating System: Windows 7/8.1/10/11 certified; macOS tested
• Mac® Resolution (min): 1920x1080
• Connector
• VGA: 1
• USB 2.0 Type A: 2
• USB 2.0 Type B: 1
• 3.5mm Audio In: 1
• 3.5mm Audio Out: 1
• Hdmi 1.4: 1
• Dvi-d: 1
• Power in: 3-pin Socket (IEC C14 / CEE22)
• Internal Speakers: 2Watts x2
• Eco Mode (Conserve): 11.5W
• Eco Mode (optimized): 13.5W
• Consumption (typical): 15.5W
• Consumption (max): 16.5W
• Voltage: AC 100-240V
• Stand-by: 0.5W
• Power Supply: Internal Power Supply
• Kensington Lock Slot: 1
• Cable Organization: Yes
• Physical Controls: 1, 2, Up, Down, Power
• Temperature: 32`b0F to 104`b0F (0`b0C to 40`b0C)
• Humidity (non-condensing): 20% to 90%
• VESA Compatible: 100 x 100 mm
• Frequency Horizontal: 24 ~ 82KHz
• Frequency Vertical: 50 ~ 75Hz
• Analog Sync: Separate/Composite/SOG - RGB Analog
• Tilt (Forward/Back): 20° / 40°
• Net (lbs): 11.5
• Net Without Stand (lbs): 10.3
• Gross (lbs): 15.4
• Net (kg): 5.2
• Net Without Stand (kg): 4.7
• Gross (kg): 7
• Packaging (in.): 25.4 x 16.6 x 6.5
• Physical (in.): 22.5 x 13.7 x 4
• Physical Without Stand (in.): 22.5 x 13.7 x 2.4
• Packaging (mm): 645 x 422 x 166
• Physical (mm): 571 x 348 x 101
• Physical Without Stand (mm): 571 x 348 x 61
• Warranty: *Warranty offered may differ from market to market
• Power Management: Energy Star standards, EPEAT
