HIKVISION Dvr 4Ch Thd+2Ch Ip 5Mp Recordi

5 MP/4 MP Turbo HD video input and live view. 20 fps in live view for the 5 MP20 signal input, and real-time frame rate in live view for the 4 MP25 and 4 MP30 signal inputs.

Key features

• Hikvision DS-7204HUHI-F1/S Series HD Turbo 4ch Standalone DVR
• Self-adaptive Turbo HD/AHD/CVBS signal input
• Up to 2-ch 4 MP IP cameras input
• Defogging function enabled for the supported analog cameras
• Long distance transmission over UTP and coaxial cable: max. 800m for 1080p and 1200m for 720p Turbo HD signal
• Compression and Recording
• One-key enable H.264+ compression to improve encoding efficiency by up to 50% and reduce data storage costs
• Full channel recording at up to 5 MP resolution
• HDMI output at up to 4K (3840 `d7 2160) resolution (DS-7208HUHI-F1/S)
• Independent CVBS output improves compatibility at the most possibility and serves as the aux output or live view output only
• One SATA interface (up to 6 TB capacity per HDD)
• Smart search for efficient playback
• Supports the 3rd party cloud storage (Dropbox/Google Drive/Microsoft OneDrive)
• Smart Function
• Supports multiple VCA (Video Content Analytics) events for both analog and smart IP cameras
• Supports line crossing detection and intrusion detection of all channels
• VCA information overlay in live view and smart playback
• VQD (Video Quality Diagnostics)
• Supports PTZ control via Omnicast VMS of Genetec protocol
• Hik Cloud P2P & DDNS (Dynamic Domain Name System) for easy network management
• compression
• input BNC interface (1.0 Vp-p, 75 `d9), supporting coaxitron connection
• Turbo HD input 5 MP20, 5 MP12, 4 MP25, 4 MP30, 3 MP18 , 1080p30, 1080p25, 720p60, 720p50,
• Audio input 4-ch, RCA (2.0 Vp-p, 1 K'd9)
• CVBS output 1-ch, BNC (1.0 Vp-p, 75 `d9), resolution: PAL: 704 `d7 576, NTSC: 704 `d7 480
• HDMI/VGA 1-ch, 1920 `d7 1080/60Hz, 1280 `d7 768/60Hz
• 1024/60Hz, 1280 `d7 720/60Hz, 1024 `d7 HDMI: 1-ch, 4K (3840 `d7 2160)/30Hz, 2K (2560
• 768/60Hz `d7 1440)/60Hz, 1920 `d7 1080/60Hz, 1280 `d7
• Video/Audio resolution
• Video bit rate 32 Kbps to 10 Mbps
• Dual stream Support
• Stream type Video, Video & Audio
• playback
• connections
• management Network TCP/IP, PPPoE, DHCP, Hik Cloud P2P, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP™, HTTPS,
• protocols ONVIF
• Hard disk
• Two-way audio 1-ch, RCA (2.0 Vp-p, 1 K'd9) (using the 1st audio input)
• Network interface 1, RJ45 10M/100M self-adaptive 1, RJ45 10M/100M/1000M self-adaptive
• External interface USB interface 2 `d7 USB 2.0 Front panel: 1 `d7 USB 2.0
• (without HDD)
• Working -10 °C to +55 °C (14 °F to 131 °F)
• Dimensions 315 `d7 242 `d7 45 mm (12.4 `d7 9.5 `d7 1.8 inch)
• Weight ≤ 1.5 kg (3.3 lb) ≤ 2 kg (4.4 lb)

Specifications

• 4/8-ch synchronous playback
• One gigabit Ethernet network interface (for DS-7208HUHI-F1/S)
• Model DS-7204HUHI-F1/S DS-7208HUHI-F1/S
• Video H.264+/H.264
• Analog video 4-ch 8-ch
• 720p30, 720p25, NTSC, PAL
• Video/Audio AHD input 1080p25, 1080p30, 720p25, 720p30
• 2-ch
• Up to 4 MP resolution
• Audio G.711u
• VGA: 1-ch, 1920 `d7 1080/60Hz, 1280 `d7
• 1024/60Hz, 1280 `d7 720/60Hz, 1024 `d7
• 768/60Hz
• Encoding 5 MP/4 MP/3 MP/1080p/720p/WD1/4CIF/VGA/CIF
• 5 MP@10fps/4 MP@15fps/3 MP@15fps
• Frame rate 1080p/720p/WD1/4CIF/VGA/CIF@25fps (P)/30fps (N)
• WD1/4CIF@12fps;
• CIF/QVGA/QCIF@25fps (P)/30fps (N)
• Audio output 1-ch, RCA (Linear, 1 K'd9)
• Audio bit rate 64 Kbps
• Synchronous 4-ch 8-ch
• Network Remote 128
• SATA 1 SATA interface
• Capacity Up to 6 TB capacity for each disk
• Rear panel: 1 `d7 USB 3.0
• Serial interface RS-485 (half-duplex)
• Alarm in/out 4/1 8/4
• Power supply 12 VDC
• Consumption ≤ 15 W ≤ 20 W
• temperature
• General Working humidity 10% to 90%
• (W `d7 D `d7 H)
