DAHUA Dome 5Mp-2.8Mm Camera
DAHUA Dome 5Mp-2.8Mm Camera
DAHUA Dome 5Mp-2.8Mm Camera
DAHUA Dome 5Mp-2.8Mm Camera

DAHUA Dome 5Mp-2.8Mm Camera

DAHUA
R 529R 629
Estimated delivery 2–4 working days
In stock
FREE NATIONWIDE DELIVERY
on orders over R 500
Quantity
In stock
  • Interest Free Payments available
  • Hassle Free Returns within 7 days
  • 6-month limited warranty
Price: R 529

Description

Operating Conditions -40`b0C to +60`b0C (-40`b0F to +140`b0F) /Less than 95% RH. Storage Conditions -40`b0C to +60`b0C (-40`b0F to +140`b0F) /Less than 95% RH.

Key features

  • Max. Resolution 2880 (H) `d7 1620 (V)
  • Scanning System Progressive
  • Min. Illumination 0.02 Lux/F2.0, 30IRE, 0 Lux IR on
  • Illuminator On/Off Control Auto;manual
  • Angle of View
  • Focus Control N/A
  • DORI distance
  • Pan / Tilt / Rotation
  • Pan/Tilt/Rotation
  • 1080P (1920 `d7 1080);960H (960 `d7 576/960 `d7 480)
  • Frame Rate
  • Video Output Video output choices of CVI/TVI/AHD/CVBS by one
  • Day/Night Auto (ICR) / Manual
  • OSD Menu Multi-language
  • BLC Mode BLC / HLC / DWDR
  • WDR dwdr
  • Gain Control AGC
  • White Balance Auto;manual
  • Smart IR Yes
  • Mirror Off/On
  • Privacy Masking Off / On (8 area, rectangle)
  • FCC (CFR 47 FCC Part 15 subpartB, ANSI C63.4-2014)
  • Eelectrical
  • Start up should be done at above -40`b0C (-40`b0F)
  • Ingress Protection & Vandal
  • Construction
  • Casing Aluminium

Specifications

  • Dh-hac-t2a51p-2.8
  • Image Sensor 1/2.7" CMOS
  • Pixel 5MP
  • Electronic Shutter Speed PAL: 1/25-1/100000 s
  • NTSC: 1/30-1/100000 s
  • S/N Ratio More than 65 dB
  • Illumination Distance 20 m (66 feet)
  • Lens
  • Lens Type Fixed lens / Fixed iris
  • Mount Type M12
  • Focal Length 3.6 mm (2.8 mm Optional)
  • Max Aperture F2.0
  • 2.8 mm: 125`b0 `d7 106`b0 `d7 56`b0
  • (diagonal `d7 horizontal `d7 vertical)
  • 3.6 mm: 104`b0 `d7 88`b0 `d7 46`b0
  • Close Focus Distance 2.8 mm: 0.8 m (2.6 ft)
  • 3.6 mm: 1.2 m (3.9 ft)
  • Lens Detect Observe Recognize Identify
  • 2.8mm 56.0 m
  • (183.7 ft)
  • 22.4 m
  • (73.5 ft)
  • 11.2 m
  • (36.7 ft)
  • 5.6 m
  • (18.4 ft)
  • 3.6mm 80 m
  • (262.5 ft)
  • 32 m
  • (105.0 ft)
  • 16 m
  • (52.5 ft)
  • 8 m
  • (26.2 ft)
  • Pan: 0`b0 - 360`b0
  • Tilt: 0`b0 - 78`b0
  • Rotation: 0`b0 - 360`b0
  • Resolution 5M (2880 `d7 1620); 4M (2560 `d7 1440);
  • PAL:5M@25 fps; 4M@25 fps; 1080P@25 fps
  • NTSC:5M@25 fps; 4M@30 fps; 1080P@30 fps
  • PAL:4M@25 fps;
  • NTSC:4M@30 fps;
  • 960H;
  • Noise Reduction 2D
  • CE (EN55032, EN55024, en50130-4,en60950-1,
  • EN 62368-1:2014+A11:2017)
  • Power Supply 12V DC `b130%
  • Power Consumption Max. 3.7W (12V DC, IR on)
  • Resistance IP67
  • Dimensions `f694 mm `d7 78 mm (`f63.7" `d7 3.07")
  • Net Weight 0.27 kg (0.60 lb)
  • Gross Weight 0.33 kg (0.73 lb)

Frequently Bought Together Frequently bought

Product Information

Categories Dahua / Security & Surveillance / Specials
Brand Dahua
Model DH-HAC-T2A51P-2.8
Image Sensor 1/2.7" CMOS"
Resolution 5MP (2880x1620)
Camera Type HDCVI Dome
Lens 3.6 mm (2.8 mm optional)
Max Aperture F2.0
Min Illumination 0.02 Lux/F2.0, 0 Lux IR on
IR Range 20 m
Signal Output CVI/TVI/AHD/CVBS via BNC
WDR DWDR
Power Input 12V DC +/-30%
Power Consumption Max 3.7 W
Operating Temperature -40C to +60C
Protection IP67
Material Aluminium
Dimensions 94 mm x 78 mm
Weight 0.27 kg
Barcode 6939554994838
