EZVIZ Eb8-4K-4G Smart Home Battery Blk

The ultimate 4K ranger, built for the wildlife and wilderness
True to its name, the EB8 Pro Ranger is like a trusted scout watching over the wild. Whether deep in the forest or across open fields, it quietly captures every moment in stunning 4K details. Its smart dual connectivity keeps you connected, whether through Wi-Fi or roaming 4G, so you’re always in the know no matter how deep you venture into the nature. Powered by advanced AOV technology with an included solar panel, it works tirelessly around the clock, guarding your property and revealing the secret lives of wildlife in their natural playground.

Specifications
Model CS-EB8-R200-1M8W4GA-CF
Camera
Image Sensor 1/2.8 8-Megapixel Progressive Scan CMOS Sensor
Minimum Illumination 0.01 Lux @(F1.2, AGC ON), 0 Lux with IR
Shutter Speed Self-adaptive shutter
Lens 4mm@ F1.2 Diagonal angle: 104°, Horizontal angle: 83° Vertical angle:44°
PT Angle Pan: 340°, Tilt: 75°
Day & Night IR-cut filter with auto switch
DNR 3D DNR
Night Vision 15 m
Video & Audio
Max Resolution 4K (3840 × 2160)
Frame Rate 15fps. Self-adaptive during network transmission
Video Compression H.265 / H.264
Video Bit Rate Ultra-HD; Full HD; Hi-Def; Adaptive bit rate.
Audio Bit Rate Self-adaptive
Max. Bitrate 4 Mbps
Function
Smart Alarm AI-powered human shape detection, AI-powered vehicle shape detection, AI-powered wild animal detection
Two-Way Talk Supports
General Function Anti-Flicker, Heart Beat, Password Protection, Watermark
Network
Wi-Fi Standard IEEE802.11b, 802.11g, 802.11n, 802.11ax
Frequency Range 2.4 GHz~2.4835 GHz
Channel Bandwidth Supports 20 MHz
Security 64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK
Transmission Rate 11b: 11Mbps, 11g: 54Mbps, 11n: 72Mbps, 11ax: 114Mbps
Wi-Fi Pairing AP pairing
Protocol EZVIZ Cloud Proprietary Protocol
Interface Protocol EZVIZ Cloud Proprietary Protocol
Minimum Network Requirement 8 Mbps
4G LTE Frequency Bands
EU: LTE FDD: B1/B3/B5/B7/B8/B20/B28, LTE TDD: B38/B40/B41 ,

LA`a3° LTE TDD: B1/B2/B3/B4/B5/B7/B8/B12/B 17/B28/B66, LTE TDD: B38/B40

Storage
Local Storage Supports microSD card (max. 512 GB)
Cloud Storage Supports EZVIZ CloudPlay storage (Subscription required)
General
Operating Conditions -20 °C to 50 °C (-4 °F to 122 °F), Humidity 95% or less (non-condensing)
IP Grade IP65
Power Supply DC 5V/2A, (Adapter needs to be purchased separately)
Battery Capacity 10,400 mAh
Power Consumption Max.10 W
Specifications
Model CS-PSP8-R100-3M
Performance Parameter
Power Voltage 5.4V ± 5%
Power Current 1.48A ± 5%
Open Circuit Voltage 6.8V ± 5%
Short Circuit Current 1.64A ± 5%
Max. Power 8W ± 5%
Interface Type-C
Solar Cell Efficiency ≥ 22%
Operation Temperature -20°C ~ 60°C (-4°F ~ 140°F) Humidity 90% or less (non-condensing)
IP Grade IP65
Solar Cell Type Monocrystalline solar cells
Power Cable Length 3 meters
General
Product Dimensions Camera: 184 × 102 × 168 mm (7.24 × 4.02 × 6.61 inch)
Solar Panel: 267.3 × 186.5 × 17.5 mm (10.51 × 5.83 × 0.69 inch)
Packaging Dimensions 300 × 204 × 175 mm (11.81 × 8.03 × 6.89 inch)
Product Weight Camera: 810 g (28.57 oz)
Solar panel: 428 g (15.10 oz)
Weight with Package 2131 g (75.18 oz )
In the box
In the box - EB8 Pro Ranger Camera
- Solar Panel 8W
- Drilling Template
- Adjustable Mounting Bracket
- Clamp Band × 2
- Clamp Adapter Bracket
- Screw Kit x 2
- Power Cable
- Quick Installation Guide
-Regulatory Information x 3
- Quick Start Guide
Certifications
Certifications CE / REACH / WEEE / RoHS
