EZVIZ H6C 2K Smart Home Camera

Specifications
Specifications CS-H6c-R200-1L3WFL
Camera
Image Sensor F2.0 @ 1/2.7" Progressive Scan CMOS
Shutter Speed Self-adaptive shutter
Lens 4mm @ F2.0, view angle: 98° (diagonal), 83° (horizontal), 44° (vertical)
Lens Mount M12
Day & Night IR-cut filter with auto-switching
DNR 3D DNR
WDR Digital WDR
Compression
Video Compression H.264 / H.265
Video Bit Rate Adaptive bit rate
Max. Resolution 2K (2304 × 1296)
Frame Rate Self-adaptive during network transmission
Network
Smart Alarm Smart human motion detection AI-powered human shape detection Loud noise detection
Wi-Fi Pairing AP pairing / Bluetooth pairing
Protocol EZVIZ Cloud Proprietary Protocol
Interface Protocol EZVIZ Cloud Proprietary Protocol
Interface
Storage Supports microSD card (max. 512 GB)
Power Type-C
Wired Network RJ45 × 1 (10 M / 100 M self-adaptive Ethernet port)
Wi-Fi
Standard IEEE802.11a, 802.11b, 802.11g, 802.11n,
Frequency Range 2.4 GHz ~ 2.4835 GHz
Channel Bandwidth Supports 20 MHz
Security WPA/WPA2, WPA-PSK/WPA2-PSK
Transmission Rate 11b 11Mbps, 11g 54Mbps, 11n MCS7, 11a 54Mbps, 11ac MCS9.11ax MCS11
Output Power (EIRP) 19 dBm
Antenna Gain 0.51 dBi
General
Operating Conditions -10°C to 45°C (14°F to 113 °F ) Humidity 95% or less (non-condensing)
Power Supply DC 5 V / 1 A
Power Consumption Max. 5 W
IR Range Max. 10 m (32.81 ft)
Dimensions 88 × 88 × 117.3 mm (3.46 × 3.46 × 4.61 inch)
Packaging Dimensions 103 × 103 × 168 mm (4.06 × 4.06 × 6.61 inch)
Net Weight 222 g (0.49 lb)
In the box
In the box - H6c G1 Camera
- Power Adapter
- Power Cable
- Drill Template
- Mounting Plate
- Screw Kit
- Regulatory Information × 2
- Quick Start Guide
Certifications
Certifications CE / UL / WEEE / REACH / RoHS
