EZVIZ H7C Dual 2k Smart Home Camera

Experience unparalleled indoor vision with the EZVIZ H7c Dual. Using two powerful lenses to ensures comprehensive coverage from top to bottom, the camera provides whole-room protection like never before. Equipped with human motion detection, two-way calling, and crystal-clear day/night vision, it keeps you connected to your home from anywhere, and doubles up your sense of safety with much more flexible features. With EZVIZ's unique dual-lens technology, the H7c Dual provides next-level protection that's usually achieved through a multi-camera setup. It uses a fixed lens and a main pan-and-tilt lens at the same time - the duo works independently or together in a way that is much smarter than your ordinary camera.

Key features

• Broader and smarter protection with dual lenses
• Dual lenses. Double protection.
• Big picture and small details both matter
• The camera allows you to understand the whole picture while paying attention to the important details. Both wide angle and close-up views are displayed simultaneously on your EZVIZ App. Tap on a specific area in the wide-angle viewing box so that a close-up shot will render much more details for you to double check.
• Overnight protection in vivid colors
• The H7c Dual uses starlight lenses to render high-quality colorful images even in low light conditions. Furthermore, it uses a built-in spotlight to deliver color night vision in complete darkness.
• When the smart night vision mode is activated, it will automatically switch its view from black-and-white to full-color upon motion detection.
• Shutter Speed Self-adaptive shutter
• Fixed Lens 2.8mm@F1.6 , view angle: 108`b0(Diagonal), 92`b0 (Horizontal), 50`b0(Vertical)
• PT Lens 6mm@F1.6 , view angle: 60`b0(Diagonal), 51`b0 (Horizontal), 28`b0(Vertical)
• Day & Night IR-cut filter with auto-switching
• WDR Digital WDR
• Compression
• Video Bit Rate Adaptive bit rate.
• Smart Alarm Motion Detection, Human Shape Detection, Loud Noise Detection, Patrol Mode Detection
• Image
• Max. Resolution 2560 `d7 1440
• Storage Micro SD card slot (Max. 512G)
• Wired Network RJ45 X 1 (10M/100M self-adaptive Ethernet port)
• Frequency Range 2.4GHz: 2.4 GHz ~ 2.4835 GHz 5GHz: 5.15GHz~5.25GHz
• Channel Bandwidth 2.4GHz Supports 20MHz 5GHz Supports 80MHz
• Transmission Rate 2.4GHz Max. Rate Support: 11b_11M'a3`ac11g_54M, 11n_MCS7_20M'a3`ac11ax_MCS11_20M 5.15-5.25GHz Max. Rate Support: 11a_54M, 11n_MCS7_20-40M'a3`ac11ac_MCS9_20-40-80M, 11ax_MCS11_20-40-80M
• Operating Conditions -10`b0C to 45`b0C ( -14 `b0F to 113 `b0F ) Humidity 95% or less (non-condensing)
• IR Range MAX. 10 meters (32.81ft)
• Dimensions 88 `d7 88 `d7 131.5 mm (3.46 `d7 3.47 `d74.69 in)
• Package Dimensions 200 `d7105 `d7105 mm (7.87 `d7 4.13 `d7 4.13 in)
• 1 x EZVIZ H7c 2K Dual-Lens Pan & Tilt Wi-Fi Camera

Specifications

• R100-8g44wf (r101-8h44wf)
• Model CS-H7c-R100-8G44WF
• Resolution Dual 2K+ Resolution
• Image Sensor 1/3" Progressive Scan CMOS
• Lens Mount M12
• DNR 3D DNR
• Video Compression H.264/H.265
• Protocol EZVIZ cloud proprietary protocol
• Interface Protocol EZVIZ cloud proprietary protocol
• Frame Rate Max:30fps; Self-Adaptive during network transmission
• Standard IEEE802.11a, IEEE802.11b, 802.11g, 802.11n,802.11ac 802.11ax
• Security WPA-PSK, WPA2-PSK, WPA3-Personal
• Output Power(EIRP) 20 dBm
• Antenna Gain 2.56dBi@2.48GHz'a3`ac3.18dBi@5.22GHz
• Power Consumption 8W max
• Power Supply DC 5V/2A
• Net Weight 270 g (9.52 oz)
• Bare Weight 499 g (17.60 oz)
• 1 x Power Adapter
• 1 x Power Cable
• 1 x Drill Template
• 1 x Mounting Plate
• 1 x Screw Kit
• 1 x Regulatory Information
• 1 x Quick Start Guide
