EZVIZ HG2 Smart Sliding Gate Motor - 600kg, 24V DC with Backup Battery

Specifications
Model CS-HG2-R200-60H
Gate Opener Motor
Power Supply 24V DC
Input Power 230V AC, 50Hz (Primary); 14.6V DC (Backup battery)
Maximum Power 220W
Rated Operating Time 15 minutes
Lock Power Output 12V DC, 1.5A
Photocell Input Up to 2 pairs, non-polarized
Continuous Open / Stop / Close Input Normally open dry contact, supports multiple inputs
Open Input Normally open dry contact, supports multiple inputs
Stop Input Normally closed dry contact by default, configurable to normally open via the EZVIZ App
Alarm Light Output 10-18V DC, 700 mA
Light Output 230V AC, Max. 100 W
Operating Conditions -30°C to +60°C, ≤95% RH (non-condensing)
Size 249 (L) x 221 (W) x 244 (H) mm
Weight 7000 g (gate opener body)
Protection Rating IP55
Remote Controllers Supports up to 8 remote controllers
Wi-Fi HaLow Repeater
Power Supply AC 110–240V
Wi-Fi Standard
Wi-Fi 6: IEEE 802.11b/g/a/n/ac/ax

Wi-Fi HaLow: IEEE 802.11ah

Wi-Fi Bands 2.4GHz / 5GHz Wi-Fi 6 HaLow
Photocells
Content in a Pair 1 TX transmitter and 1 RX receiver
Power Supply 12V DC
Maximum Rated Power 0.8W (TX & RX combined)
Input
1 normally closed dry contact output

1 normally open dry contact output

Distance Up to 10 meters
Operating Conditions -30°C to 60°C, ≤95% RH (non-condensing)
Protection Rating IP55
Remote Controller
Frequency 433 MHz
Open Field Range 60 meters
Power Supply 3V (CR2032 battery)
Buttons 4 buttons (plus 1 reset button inside)
Battery Lifetime Approximately 1 year based on 20 uses of 2 seconds per day
Operating Conditions -10°C to 45°C, ≤95% RH (non-condensing)
Certifications
Certifications CE / REACH / WEEE / RoHS
