Hikvision 2Mp Ip Bullet 2.8 Mm

Clear imaging against strong back light due to DWDR technology. Color: 0.01 Lux @(F2.0, AGC ON), B/W: 0 Lux with IR.

Key features

• EXIR 2.0: advanced infrared technology with long IR range
• Image Sensor
• Max. Resolution
• Min. Illumination
• Shutter Time
• Day & Night
• IR cut filter
• Angle Adjustment
• Pan: 0`b0 to 360`b0, tilt: 0`b0 to 180`b0, rotate: 0`b0 to 360`b0
• Focal Length & FOV
• 2.8 mm, horizontal FOV 112.1`b0, vertical FOV 60.0`b0, diagonal FOV 132.2`b0
• 4 mm, horizontal FOV 90.2`b0, vertical FOV 48.6`b0, diagonal FOV 107.6`b0
• Iris Type
• Fixed
• Illuminator
• Supplement Light Type
• IR
• Supplement Light Range
• Smart Supplement Light
• Yes
• IR Wavelength
• Main Stream
• 50 Hz: 25 fps (1920 `d7 1080, 1280 `d7 720)
• 60 Hz: 30 fps (1920 `d7 1080, 1280 `d7 720)
• Sub-Stream
• 50 Hz: 25 fps (640 `d7 480, 640 `d7 360)
• 60 Hz: 30 fps (640 `d7 480, 640 `d7 360)
• Baseline Profile/Main Profile/High Profile
• Main Profile
• Region of Interest (ROI)
• Protocols
• Tcp/ip, icmp, http, https, FTP, dhcp, DNS, ddns, RTP, rtsp, rtcp, NTP, upnp, smtp, igmp, qos, ipv6, bonjour, ipv4, UDP, ssl/tls
• Simultaneous Live View
• API
• Open Network Video Interface, ISAPI
• User/Host
• Up to 32 users. 3 levels: administrator, operator and user
• Client
• Web Browser
• Image
• Image Settings
• Saturation, brightness, contrast, sharpness, AGC, white balance adjustable by client software or web browser.
• Day/Night Switch
• Day, Night, Auto, Schedule
• Wide Dynamic Range (WDR)
• Digital WDR
• SNR
• Image Enhancement
• 1 RJ45 10 M/100 M self-adaptive Ethernet port
• Event
• Basic Event
• Motion detection, video tampering alarm, exception
• Linkage
• Upload to FTP, notify surveillance center, send email
• 12 VDC `b1 25%, 0.4 A, max. 5 W, `d85.5 mm coaxial power plug
• PoE: 802.3af, Class 3, 36 V to 57 V, 0.2 A to 0.15 A, max. 6.5 W
• 177.6 mm `d7 66.2 mm `d7 67.8 mm (7.0" `d7 2.6" `d7 2.7")
• 216 mm `d7 121 mm `d7 118 mm (8.5" `d7 4.8" `d7 4.6")
• Approx. 270 g (0.6 lb.)
• Approx. 490 g (1.1 lb.)
• 30 `b0C to 60 `b0C (-22 `b0F to 140 `b0F). Humidity: 95% or less (non-condensing)
• Startup and Operating Conditions
• Language
• English, Ukrainian
• Anti-flicker, heartbeat, mirror, password protection, privacy mask, watermark, IP address filter
• Approval
• EMC
• FCC SDoC (47 CFR Part 15, Subpart B); CE-EMC (EN 55032: 2015, EN 61000-3-2: 2014, EN 61000-3-3: 2013, EN 50130-4: 2011 +A1: 2014); RCM (AS/NZS CISPR 32: 2015); IC VoC (ICES-003: Issue 6, 2016); KC (KN 32: 2015, KN 35: 2015)
• Safety
• UL (UL 60950-1); CB (IEC 60950-1:2005 + Am 1:2009 + Am 2:2013, IEC 62368-1:2014); CE-LVD (EN 60950-1:2005 + Am 1:2009 + Am 2:2013, IEC 62368-1:2014); BIS (IS 13252(Part 1):2010+A1:2013+A2:2015)
• CE-RoHS (2011/65/EU); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2006)
• Protection

Specifications

• Ds-2cd1023g0e-i2.8mm
• 2 MP Fixed Bullet Network Camera
• High quality imaging with 2 MP resolution
• Efficient H.265+ compression technology
• Water and dust resistant (IP67)
• 1/2.7" Progressive Scan CMOS
• 1920 `d7 1080
• 1/3 s to 1/100, 000 s
• Lens
• Lens Mount
• M12
• Aperture
• F2.0
• Up to 30 m
• 850 nm
• Main Stream: H.265/H.264/H.264+/H.265+
• Sub-Stream: H.265/H.264/MJPEG
• 32 Kbps to 8 Mbps
• H.264 Type
• H.265 Type
• 1 fixed region for main stream
• Up to 6 channels
• iVMS-4200, Hik-Connect
• Plug-in required live view: IE 10+
• Plug-in free live view: Chrome 57.0+, Firefox 52.0+
• Local service: Chrome 57.0+, Firefox 52.0+
• ≥ 52 dB
• BLC, 3D DNR
• IP67 (IEC 60529-2013)
