Hikvision 4MP ColorVu AcuSense Bullet IP

# HIKVISION 4MP Smart Hybrid Light with ColorVu Fixed Bullet Network Camera

The **HIKVISION 4MP Smart Hybrid Light with ColorVu Fixed Bullet Network Camera** is a professional intelligent surveillance camera combining **4MP high-resolution imaging, ColorVu technology, Smart Hybrid Light, deep-learning human and vehicle classification, active deterrence, and two-way audio** in a durable IP67-rated metal housing.

Featuring a highly sensitive **1/1.8" Progressive Scan CMOS sensor** and large **F1.0 aperture**, the camera delivers exceptional colour imaging in extremely low-light environments, with minimum colour illumination as low as **0.0005 Lux**. Its Smart Hybrid Light system combines **infrared and white supplementary lighting with a range of up to 60 metres**, providing flexible illumination according to the surveillance environment.

For challenging scenes containing strong backlighting, **130 dB Wide Dynamic Range (WDR)** helps maintain detail in both bright and dark areas. Efficient **H.265+ compression** reduces bandwidth and storage requirements while maintaining high-quality surveillance footage.

The camera also incorporates deep-learning technology for **human and vehicle classification**, helping security systems focus on relevant targets. Active deterrence capabilities include a **strobe light and audible warning**, while the built-in microphone and speaker provide convenient **real-time two-way audio communication**.

With support for a microSD card of up to **512GB**, PoE, alarm and audio interfaces, perimeter protection, face capture, and an IP67 weather-resistant construction, this camera is designed for advanced residential, commercial, retail, warehouse and perimeter security applications.

## Key Features

- High-quality **4MP resolution**
- Maximum resolution of **2688 × 1520**
- **ColorVu** technology for enhanced colour imaging
- **Smart Hybrid Light** with IR and white light
- Supplementary lighting range of up to **60 metres**
- Ultra-low-light colour performance down to **0.0005 Lux**
- Large **F1.0 aperture**
- **130 dB WDR** for strong backlight environments
- Deep-learning **human and vehicle classification**
- Active **strobe light and audio alarm**
- Built-in microphone and speaker
- **Two-way audio** communication
- **H.265+** efficient video compression
- Built-in microSD card slot supporting up to **512GB**
- Face capture
- Perimeter protection
- Audio input and output
- Alarm input and output
- Supports **12V DC and PoE**
- Durable metal construction
- **IP67** water and dust resistance

## Camera

**Image Sensor:**
1/1.8" Progressive Scan CMOS

**Maximum Resolution:**
2688 × 1520

**Minimum Illumination:**
Colour: 0.0005 Lux @ F1.0, AGC ON
0 Lux with supplementary light

**Shutter Speed:**
1/3 s to 1/100,000 s

**Day & Night:**
IR cut filter

**Angle Adjustment:**

- Pan: 0° to 360°
- Tilt: 0° to 90°
- Rotate: 0° to 360°

## Lens

**Lens Type:**
Fixed focal lens

**Available Focal Lengths:**
2.8 mm or 4 mm

**Lens Mount:**
M16

**Iris Type:**
Fixed

**Aperture:**
F1.0

### 2.8 mm Lens

- Horizontal FOV: 104.0°
- Vertical FOV: 54.4°
- Diagonal FOV: 126.7°
- Depth of Field: 2.5 m to ∞

### 4 mm Lens

- Horizontal FOV: 89.2°
- Vertical FOV: 45.5°
- Diagonal FOV: 108.2°
- Depth of Field: 3.1 m to ∞

## DORI Distance

### 2.8 mm Lens

- Detect: 61 m
- Observe: 24 m
- Recognise: 12 m
- Identify: 6 m

### 4 mm Lens

- Detect: 75 m
- Observe: 30 m
- Recognise: 15 m
- Identify: 7 m

## Smart Hybrid Light

The camera incorporates both **infrared and white supplementary lighting**, providing flexible illumination for different surveillance conditions.

**Supplement Light Type:**
IR and White Light

**Supplement Light Range:**
Up to 60 metres

**Smart Supplement Light:**
Yes

**IR Wavelength:**
850 nm

Smart Hybrid Light technology allows the camera to make intelligent use of its supplementary lighting to provide clearer surveillance footage in low-light and nighttime environments.

## Video

### Main Stream

**50 Hz:**

- 25 fps @ 2688 × 1520
- 25 fps @ 1920 × 1080
- 25 fps @ 1280 × 720

**60 Hz:**

- 30 fps @ 2688 × 1520
- 30 fps @ 1920 × 1080
- 30 fps @ 1280 × 720

### Sub-Stream

**50 Hz:**

- 25 fps @ 1280 × 720
- 25 fps @ 640 × 480
- 25 fps @ 640 × 360

**60 Hz:**

- 30 fps @ 1280 × 720
- 30 fps @ 640 × 480
- 30 fps @ 640 × 360

### Third Stream

**50 Hz:**

- 10 fps @ 1920 × 1080
- 10 fps @ 1280 × 720
- 10 fps @ 640 × 480
- 10 fps @ 640 × 360

**60 Hz:**

- 10 fps @ 1920 × 1080
- 10 fps @ 1280 × 720
- 10 fps @ 640 × 480
- 10 fps @ 640 × 360

*Third stream support is available under certain settings.*

## Video Compression

**Main Stream:**

- H.265
- H.264
- H.264+
- H.265+

**Sub-Stream:**

- H.265
- H.264
- MJPEG

**Third Stream:**

- H.265
- H.264

**Video Bit Rate:**
32 Kbps to 8 Mbps

**H.264 Profiles:**

- Baseline Profile
- Main Profile
- High Profile

**H.265 Profile:**
Main Profile

**Bit Rate Control:**
CBR / VBR

**Scalable Video Coding:**
Supports H.264 and H.265 encoding

**Region of Interest:**
1 fixed ROI region for the main stream and sub-stream

## Audio

The camera`s integrated audio system provides **real-time two-way communication**, making it possible to communicate directly through the surveillance system.

**Audio Type:**
Mono

**Audio Compression:**

- G.711
- G.722.1
- G.726
- MP2L2
- PCM
- MP3
- AAC-LC

**Audio Sampling Rates:**

- 8 kHz
- 16 kHz
- 32 kHz
- 44.1 kHz
- 48 kHz

**Environment Noise Filtering:**
Yes

### Audio Bit Rates

- G.711 `ec-law/A-law: 64 Kbps
- G.722.1: 16 Kbps
- G.726: 16 Kbps
- MP2L2: 32 to 192 Kbps
- MP3: 8 to 320 Kbps
- AAC-LC: 16 to 64 Kbps

## Network

**Supported Protocols:**

TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SNMP, WebSocket, WebSockets, SRTP and SFTP.

**Simultaneous Live View:**
Up to 6 channels

**API Support:**

- Open Network Video Interface Profile S
- Profile G
- Profile T
- ISAPI
- SDK
- ISUP

## Users & Access

Supports up to **32 users**.

Three user levels are available:

- Administrator
- Operator
- User

## Network Security

Security features include:

- Password protection
- Complicated password support
- HTTPS encryption
- 802.1X authentication
- EAP-TLS
- EAP-LEAP
- EAP-MD5
- Watermark
- IP address filtering
- Basic and digest authentication for HTTP/HTTPS
- WSSE authentication
- Open Network Video Interface digest authentication
- RTP/RTSP over HTTPS
- Control timeout settings
- Security audit log
- TLS 1.1 / 1.2 / 1.3
- MAC address host authentication

## Network Storage

**NAS Support:**

- NFS
- SMB/CIFS

**Auto Network Replenishment:**
ANR supported

## Client Software

Compatible with:

- iVMS-4200
- Hik-Connect
- Hik-Central

## Web Browser Support

**Plug-in Required Live View:**

- Internet Explorer 10
- Internet Explorer 11

**Plug-in-Free Live View:**

- Chrome 57.0+
- Firefox 52.0+
- Edge 89+

**Local Service:**

- Chrome 57.0+
- Firefox 52.0+
- Edge 89+

## Image Settings

**Image Parameters Switch:**
Yes

**Adjustable Image Settings:**

- Rotate mode
- Saturation
- Brightness
- Contrast
- Sharpness
- Gain
- White balance

Settings can be adjusted through compatible client software or a web browser.

**Day/Night Modes:**

- Day
- Night
- Auto
- Schedule

**Image Enhancement:**

- BLC
- HLC
- 3D DNR
- Defog

**Signal-to-Noise Ratio:**
≥ 52 dB

**Wide Dynamic Range:**
130 dB WDR

**Privacy Mask:**
4 programmable polygon privacy masks

## Interface

**Ethernet:**
1 × RJ45 10M/100M self-adaptive Ethernet port

### On-Board Storage

Built-in memory card slot supporting:

- microSD
- microSDHC
- microSDXC

**Maximum Capacity:**
512GB

### Built-in Microphone

1 × built-in microphone

### Built-in Speaker

**Maximum Power Consumption:**
2W

**Maximum Sound Pressure Level:**
97 dB at 10 cm

## External Audio Interface

**Audio Input:**

1 × line input using two-core terminal block

- Maximum input amplitude: 3.3 Vpp
- Input impedance: 4.7 kΩ
- Interface type: Non-equilibrium

**Audio Output:**

1 × line output using two-core terminal block

- Maximum output amplitude: 3.3 Vpp
- Output impedance: 100 Ω
- Interface type: Non-equilibrium

## Alarm Interface

- 1 × alarm input
- 1 × alarm output
- Maximum output: 24 VDC / 24 VAC, 1A

**Reset Key:**
Yes

## Basic Events

The camera supports:

- Motion detection
- Human and vehicle target classification
- Video tampering alarm
- Exception detection

Motion detection supports alarm triggering according to specified **human and vehicle target types**.

## Smart Events

**Scene Change Detection:**
Supported

## Perimeter Protection

Advanced perimeter protection includes:

- Line crossing detection
- Intrusion detection
- Region entrance detection
- Region exiting detection

These functions support alarm triggering according to specified **human and vehicle targets**, helping reduce irrelevant alerts and improving the effectiveness of perimeter surveillance.

## Deep Learning Functions

**Face Capture:**
Yes

**Human Classification:**
Yes

**Vehicle Classification:**
Yes

Deep-learning algorithms allow the camera to focus security events on people and vehicles, providing more intelligent event filtering.

## Active Deterrence

The camera provides an additional layer of security through **active strobe-light and audible-warning functions**.

When configured with supported events, the camera can activate visual and audible warnings to help deter intruders while simultaneously notifying the surveillance system.

## Event Linkage

Supported linkage actions include:

- Upload to FTP
- Upload to NAS
- Upload to memory card
- Notify surveillance centre
- Send email
- Trigger alarm output
- Trigger recording
- Trigger capture
- Audible warning
- Strobe light

## Power

### 12V DC

- 12 VDC ±25%
- 0.88A
- Maximum power consumption: 10.5W
- `d85.5 mm coaxial power plug
- Reverse polarity protection

### PoE

- IEEE 802.3af
- Class 3
- Maximum power consumption: 12.5W

The camera`s PoE capability allows network data and power to be supplied through a compatible Ethernet connection, helping simplify installation.

## Construction

The camera features a robust metal construction.

**Material:**

- Front cover: Metal
- Body: Metal
- Bracket: Metal

## Dimensions & Weight

**Camera Dimensions:**
286.7 × 93.3 × 91.2 mm

**Package Dimensions:**
386 × 156 × 155 mm

**Camera Weight:**
Approx. 1,205 g

**Weight with Packaging:**
Approx. 1,920 g

## Operating & Storage Conditions

**Operating Temperature:**
-30°C to 60°C

**Operating Humidity:**
95% or less, non-condensing

**Storage Temperature:**
-30°C to 60°C

**Storage Humidity:**
95% or less, non-condensing

## General Functions

Supported general functions include:

- Heartbeat
- Mirror
- Flash log
- Password reset via email
- Pixel counter
- Anti-banding

## Weather Protection

**Protection Rating:**
IP67

**Standard:**
IEC 60529-2013

The **IP67 rating** provides protection against water and dust, making the camera suitable for demanding indoor and outdoor surveillance installations.

## Language Support

The camera supports **33 languages**, including:

English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), and Ukrainian.

## Approvals & Compliance

### EMC

- CE-EMC: EN 55032:2015+A1:2020
- EN 50130-4:2011+A1:2014
- EN IEC 61000-3-2:2019+A1:2021
- EN 61000-3-3:2013+A1:2019+A2:2021
- RCM: AS/NZS CISPR 32:2015
- IC: ICES-003 Issue 7
- KC: KN32:2015
- KC: KN35:2015

### Safety

- UL: UL 62368-1
- CB: IEC 62368-1:2014+A11
- CE-LVD: EN 62368-1:2014/A11:2017

### Environmental

**CE-RoHS:**
2011/65/EU

### Protection

**IP67:**
IEC 60529-2013

## Ideal Applications

The HIKVISION 4MP Smart Hybrid Light with ColorVu Fixed Bullet Network Camera is suitable for a wide variety of professional security applications, including:

- Homes and residential properties
- Retail stores
- Warehouses
- Offices
- Business premises
- Building entrances
- Parking areas
- Perimeter surveillance
- Factories
- Schools
- Commercial properties
- Outdoor security installations

With its combination of **4MP resolution, ColorVu imaging, Smart Hybrid Light with up to 60m illumination, 130 dB WDR, human and vehicle classification, active strobe and audio deterrence, two-way audio, face capture, 512GB local storage support, PoE and IP67 protection**, this HIKVISION fixed bullet network camera provides an intelligent and comprehensive security solution for modern surveillance installations.
