Description

Up to 1-ch facial recognition for video stream, or up to 4-ch facial recognition for face picture. HDMI1 output: 4K (3840 `d7 2160)/60Hz, 4K (3840 `d7 2160)/30Hz, 2K (2560 `d7 1440)/60Hz, 1920 `d7 1080/60Hz, 1600 `d7 1200/60Hz, 1280 `d7 1024/60Hz, 1280 `d7 720/60Hz, 1024 `d7 768/60Hz, HDMI1/VGA simultaneous output HDMI2 output:1920 `d7 1080/60Hz, 1280 `d7 1024/60Hz, 1280 `d7 720/60Hz, 1024 `d7 768/60Hz, HDMI2/VGA independent output.

Key features

  • Intelligent analytics based on deep learning algorithm
  • Plug & Play with 16 Power-over-Ethernet (PoE) interfaces
  • Incoming Bandwidth
  • Outgoing Bandwidth
  • 1-ch, 1920 `d7 1080/60Hz, 1280 `d7 1024/60Hz, 1280 `d7 720/60Hz, 1024 `d7 768/60Hz,
  • 1-ch, BNC (1.0 Vp-p, 75 `d9), resolution: PAL: 704 `d7 576, NTSC: 704 `d7 480
  • Live View Window Division
  • Aux Port Window Division
  • Decoding Capability
  • Synchronous Playback
  • Smart Analysis
  • Face Picture Library
  • Up to 16 face picture libraries, with up to 10,000 face pictures in total (each picture ≤ 512 KB, total capacity ≤ 150 MB)
  • List Library Capacity
  • List Library
  • Face Picture Comparison
  • Face Capture
  • 1-ch human face capture (HD network camera, up to 4 MP, H.264/H.265)
  • HDD Management
  • HDD No.
  • Recording Management
  • Playback Mode
  • Normal/Smart, Event, Tag, Eternal File
  • Front panel: 2 `d7 USB 2.0; Rear panel: 1 `d7 USB 3.0
  • Alarm Input/Output
  • PoE
  • PoE Standard
  • Consumption (Without HDD)
  • Working Temperature
  • Working Humidity
  • Chassis
  • 445 `d7 400 `d775 mm ( 17.5"`d7 15.7" `d7 3.0")

Specifications

  • Ds-7716nxi-i4/16p/s
  • 16-ch 1.5U 16 POE AcuSense 4K NVR
  • H.265+/H.265/H.264+/H.264 video formats
  • Up to 4-ch perimeter protection
  • Up to 16-ch IP camera inputs
  • Up to 16-ch 1080p decoding capability
  • Up to 160 Mbps incoming bandwidth
  • 16
  • 160 Mbps
  • 256 Mbps
  • 12mp/8mp/7mp/6mp/5mp/4mp/3mp/1080p/uxga/720p/vga/4cif/dcif/2cif/cif/qcif
  • 2-ch HDMI, 1-ch VGA
  • 1/4/6/8/9/16/25/32/36
  • H.265;h.265+;h.264;h.264+;mpeg4
  • 16-ch @ 1080p (30 fps)
  • 16-ch
  • G.711ulaw;G.711alaw;G.722;G.726;MP2L2
  • 1-ch, RCA (Linear, 1 K'd9)
  • 1-ch, RCA (2.0 Vp-p, 1 K'd9)
  • 1w
  • 4-ch face picture comparison alarm
  • 4 SATA interfaces
  • 1 eSATA interface
  • 1, RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface
  • RS-485 (half-duplex), RS-232, Keyboard
  • 16/4
  • 16, RJ-45 10/100 Mbps self-adaptive Ethernet interface
  • IEEE 802.3 af/at
  • ≤ 200W
  • ≤ 360 W
  • ≤ 30 W
  • 10℃`a1`ab'a3`ab55℃
  • 10`a3`a5`a1`ab90`a3`a5
  • 1.5U
  • ≤ 7 kg (15.4 lb)

Frequently Bought Together Frequently bought

Product Information

Categories Hikvision / Security & Surveillance / Specials
Brand Hikvision
Model DS-7716NXI-I4/16P/S
Channels 16-ch IP camera inputs
PoE Ports 16 PoE interfaces
PoE Standard IEEE 802.3 af/at
PoE Power ≤ 200 W
Video Format H.265+/H.265/H.264+/H.264
Incoming Bandwidth 160 Mbps
Outgoing Bandwidth 256 Mbps
HDMI Output 4K (3840 x 2160)/60Hz
SATA 4 SATA interfaces
Power ≤ 360 W
Chassis 1.5U
Dimensions 445 x 400 x 75 mm
Weight ≤ 7 kg (without HDD)
Barcode 6942160419725
