TENDA 6-Port Desktop Switch With 4-PoE

TEF1106P-4-63W is an unmanaged PoE switch with 2 uplink ports, independently designed by Tenda. Compliant with IEEE 802.3at/af standards, it can identify PoE-powered devices intelligently. The switch supplies a maximum PoE power output of 63 W, and 30 W for a single port. Featured with extend mode and QoS function, TEF1106P-4-63W is a ideal choice for SMBs, supermarkets and restaurants with small-sized video surveillance requirement. Funtions Standard: the switch functions as a common unmanaged switch and all the ports of the switch can communicate with each other.

Key features

• (Data/Power)
• Level of protection Lightning protection for ports: 6KV
• Forwarding mode Store-and-forward
• Extend Mode: If Extend mode is enabled, Port 1-4 will be isolated respectively (10Mbps auto-negotiation).And the delivery distance of powering and network data is up to 250m (10Mbps).

Specifications

• Network standards IEEE 802.3/3u/3x, IEEE 802.3af/at
• LED Indicator 6 * Link/Ack LED indicators
• 1 * Power LED indicator
• Interfaces 4*10/100 Base-TX Ethernet ports
• 2*10/100 Base-TX Ethernet ports (Data)
• Transmission media Recommended: CAT5/5e UTP or better
• Dimension 100.0mmx100.0mmx26.0mm
• Lightning protection for power: 4KV
• Air discharge: `b110kV
• Contact discharge: `b18kV
• Switch capacity 1.2 Gbps
• Packet forwarding rate 0.89Mpps
• Buffer 448K
• MAC address table 1 K
• PoE budget Single port: AF: 15.4W, AT: 30W
• Whole device: 63W
• Input voltage 100`a3`ad240V AC 50/60Hz
• 51V /1.25A DC'a3`a8Power Adapter `a3`a9
• Mounting Desktop mounting: support
• Wall mounting: support
• Rack mounting:non-support
• Environment Operating Temperature: 0℃~45℃
• Storage Temperature: -40℃~70℃
• Operating Humidity: 10%~90% non-condensing
• Storage Humidity: 5%~90% non-condensing
• Certification FCC'a1`a2CE'a1`a2RoHS
