COMPTYCO AUA-M8 Fiber Optic Thermal

COMPTYCO AUA-M8 Fiber Optic Thermal Stripper – Heated Fibre Stripping Tool for Fusion Splicing

The COMPTYCO AUA-M8 Fiber Optic Thermal Stripper is a professional heated fibre stripping tool designed for fiber optic fusion splicing, FTTH installation and fibre preparation. By using controlled heat to soften the fibre coating, the AUA-M8 helps technicians remove coatings cleanly and efficiently while preparing optical fibres for fusion splicing.

Supporting multiple fibre configurations, including bare fibre, bundled fibre, ribbon fibre and invisible fibre, the AUA-M8 combines 8 temperature settings, a precision 20mm limit blade, automatic heating and a 3500mAh rechargeable lithium battery in a compact and portable design.

KEY FEATURES & BENEFITS
???? Heated Fibre Stripping Technology

The AUA-M8 uses controlled thermal heating to soften fibre coatings before stripping. This helps provide smooth coating removal for fibre preparation and fusion splicing applications.

The automatic heating system provides intelligent constant-temperature control for consistent operation.

???? Multi-Fibre Stripping Capability

The AUA-M8 supports multiple fibre configurations:

Bare Fibre: 1–48 cores
Bundled Fibre: 1–15 cores
Ribbon Fibre: 2–24 cores
Invisible Fibre: 1–12 cores

This makes the tool suitable for a variety of fibre installation and splicing requirements.

????️ 8 Temperature Settings

The thermal stripper provides 8 selectable temperature levels across two operating modes.

HEATER Mode:

120°C
130°C
145°C
160°C

SAVE MODE:

110°C
120°C
130°C
145°C

The different temperature settings allow the tool to accommodate different coating materials and operating conditions.

???? Precision 20mm Limit Blade

The AUA-M8 incorporates a 20mm widened limit blade edge designed to provide controlled stripping and accurate blade-gap positioning.

It supports a stripping coating length of up to 32mm or less, helping achieve clean and consistent fibre preparation.

???? 3500mAh Rechargeable Battery

The built-in 3500mAh lithium battery provides approximately 4 hours of operation or around 400 stripping cycles on a full charge.

Charging is convenient through the integrated USB Type-C charging port.

???? Compact & Portable Design

Weighing approximately 230g, the AUA-M8 is designed for portability and field use. Its compact dimensions make it convenient to carry alongside other fibre optic installation and fusion splicing equipment.

TECHNICAL SPECIFICATIONS
Specification Details
Brand COMPTYCO
Model AUA-M8
Product Type Fiber Optic Thermal Stripper
Application Fibre Preparation / Fusion Splicing
Applicable Fibre Types Bundled Fibre / Bare Fibre / Ribbon Fibre / Invisible Fibre
Bare Fibre Capacity 1–48 Cores
Bundled Fibre Capacity 1–15 Cores
Ribbon Fibre Capacity 2–24 Cores
Invisible Fibre Capacity 1–12 Cores
Applicable Cladding Diameter 25 `ecm
Stripping Coating Length ≤32mm
Limit Blade Edge Width 20mm
Heating Modes HEATER / SAVE MODE
HEATER Temperatures 120°C / 130°C / 145°C / 160°C
SAVE MODE Temperatures 110°C / 120°C / 130°C / 145°C
Maximum Heating Temperature ≤160°C
Battery Type Built-in Lithium Battery
Battery Capacity 3500mAh
Charging Interface USB Type-C
Operating Time Approx. 4 Hours
Stripping Cycles Approx. 400 Cycles
Host Dimensions 13.5 × 4.3 × 3.2cm
Host Weight Approx. 230g
Package Dimensions 17.1 × 8 × 5cm
Package Weight Approx. 340g
IDEAL APPLICATIONS

The COMPTYCO AUA-M8 Fiber Optic Thermal Stripper is suitable for:

Fiber optic fusion splicing
FTTH fibre installation
Fibre optic cable preparation
Telecom network installation
Fibre splicing preparation
Ribbon fibre preparation
Multi-core fibre stripping
Fibre optic repair and maintenance
Professional fibre technicians
Field fibre installation
PACKAGE CONTENTS

The COMPTYCO AUA-M8 package includes:

1 × COMPTYCO AUA-M8 Thermal Stripper
1 × USB Type-C Charging Cable
2 × Adjusting Wrenches
1 × Pair of Tweezers
1 × Cleaning Brush
1 × Zipper Carrying Bag
1 × Lanyard Strap
1 × Certificate of Conformity
1 × User Instruction Manual
1 × Packaging Box
PROFESSIONAL FIBRE STRIPPING SOLUTION

The COMPTYCO AUA-M8 Fiber Optic Thermal Stripper provides a convenient solution for technicians who need efficient fibre coating removal before fusion splicing. With 8 heating levels, multi-fibre compatibility, precision stripping control, automatic heating, a 3500mAh rechargeable battery and compact portable construction, it is an excellent addition to a professional FTTH and fibre optic splicing toolkit.
