COMPTYCO KP600 UPC OTDR Fiber Optic Test

COMPTYCO KP600 UPC OTDR Fiber Optic Tester – 1310/1550nm Dual-Wavelength Fibre Network Analyzer
Short Description (Key Features)
9-in-1 Multifunctional Fiber Network Tester: Combines OTDR, Event Map, Optical Power Meter (OPM), Visual Fault Locator (VFL), Optical Light Source (OLS), Optical Loss Testing, Network Testing, LED Flashlight, and RJ45 Wire Tracking in one compact handheld device.
1310/1550nm Dual-Wavelength OTDR: Designed for G.652D single-mode fibre testing, with a dynamic range of up to 24/22dB and selectable testing distances from 100m to 100km.
High-Precision Fault Detection: Features a 2.5m event blind area, 8m attenuation blind zone, up to 20,000 sampling points, and loss resolution down to 0.001dB.
3.5-Inch HD Multi-Touch Display: Provides a clear, high-definition colour touchscreen with soft backlighting for convenient operation and field visibility.
One-Click Automatic Measurement: Automatically performs fibre distance, loss, attenuation and event analysis, helping technicians identify faults quickly and efficiently.
Advanced OPM & VFL Functions: The OPM supports 9 calibration wavelengths from 850nm to 1650nm with a measurement range of -50 to +26dBm, while the VFL provides ≥10mW output for visible fault tracing beyond 10km.
Integrated Optical Light Source: Supports 1310/1550nm output with CW, 270Hz, 330Hz, 1kHz and 2kHz modulation modes for optical loss and fibre link testing.
RJ45 Cable Testing & Wire Tracking: Performs cable line sequence checks, cable length measurements and wire tracing using the included remote adapter and receiver probe.
4000mAh Battery & Type-C Charging: Built-in rechargeable lithium battery provides convenient field operation, while Type-C charging simplifies power management.
Compact Palm-Sized Design: Measuring only 173 × 80 × 38mm and weighing approximately 360g, the KP600 is designed for portable fibre installation, maintenance and troubleshooting.
Long Product Description

The COMPTYCO KP600 UPC OTDR Fiber Optic Tester is a compact, multifunctional fibre network testing instrument designed for FTTH installation, fibre optic maintenance, network troubleshooting and field technicians. Combining multiple optical and copper cable testing functions into one handheld device, it eliminates the need to carry several separate testers.

Operating at 1310nm and 1550nm dual wavelengths, the KP600 provides accurate fibre length measurement, attenuation analysis, optical loss testing and fault location on G.652D single-mode fibre. With a dynamic range of up to 24/22dB, testing distances can be selected from 100m through to 100km, making the instrument suitable for a wide range of fibre network applications.

The built-in 3.5-inch HD multi-touch colour display provides an intuitive interface for navigating test functions and viewing measurement results. Its one-click automatic measurement capability simplifies testing by automatically analysing fibre distance, loss, attenuation and events, while the integrated Event Map provides a visual representation of the fibre link.

Integrated Testing Functions

1. OTDR & Event Map

The OTDR module measures fibre length, attenuation, reflection loss and fault locations over distances up to 100km. With a 2.5m event blind area and 8m attenuation blind zone, the KP600 can assist with identifying fibre breaks, connectors, splices and other network events. Test results can be stored in standard .SOR format.

2. Optical Power Meter (OPM)

The integrated OPM supports nine calibration wavelengths:

850nm
1270nm
1300nm
1310nm
1490nm
1550nm
1577nm
1625nm
1650nm

It provides an optical power measurement range of -50 to +26dBm, making it suitable for measuring optical signal levels across various fibre network systems.

3. Visual Fault Locator (VFL)

The VFL emits visible red laser light at an output of ≥10mW, helping technicians identify fibre breaks, severe bends, poor connections and other visible faults. Its stated detection range extends beyond 10km, depending on fibre and environmental conditions.

4. Optical Light Source (OLS)

The integrated optical light source supports 1310nm and 1550nm wavelengths and multiple modulation modes, including CW, 270Hz, 330Hz, 1kHz and 2kHz. This allows the KP600 to be used together with an optical power meter for fibre link loss testing.

5. RJ45 Network Testing & Wire Tracking

In addition to optical fibre testing, the KP600 provides copper network cable testing functions. It can perform RJ45 line sequence checks, cable length measurements and wire tracking, with the included remote adapter and receiver probe helping technicians identify and trace cables.

6. Storage & Data Management

The tester can internally store at least 1,000 test files and supports external SD card expansion. OTDR measurement data can be saved in standard .SOR format, allowing results to be retained for documentation, analysis and maintenance records.

7. Portable Power System

A built-in 4000mAh / 3.7V lithium battery powers the tester, while the Type-C charging interface provides convenient charging and data connectivity. The integrated rear LED lamp can also provide additional illumination when working in dark or poorly lit areas.

Key Applications
FTTH fibre optic installation
Fibre network commissioning
Optical cable maintenance
Fibre fault and breakpoint detection
Optical loss and attenuation testing
Fibre link performance verification
Connector and splice troubleshooting
Telecom network maintenance
Data centre fibre testing
ISP and broadband network maintenance
RJ45 network cable testing
Copper cable tracing and identification
Field service and technical diagnostics
Technical Specifications
Parameter / Feature Specification
Brand COMPTYCO
Model KP600 UPC
Product Type Multifunctional Palm OTDR Fibre Optic Tester
OTDR Wavelengths 1310 / 1550 ±20nm
OTDR Type Dual Wavelength
Compatible Fibre G.652D Single-Mode Fibre
Dynamic Range 24 / 22dB
Event Blind Area 2.5m
Attenuation Blind Zone 8m
Measuring Ranges 100m / 500m / 1km / 2km / 5km / 10km / 20km / 40km / 60km / 100km
Pulse Widths 5ns / 10ns / 20ns / 50ns / 100ns / 275ns / 500ns / 1`ecs / 2`ecs / 5`ecs / 10`ecs
Maximum Sampling Points 20,000 points
Sampling Resolution 25cm to 8m
Loss Resolution 0.001dB
Range Resolution 0.001m
File Format Standard .SOR
Internal Storage ≥1,000 files
External Storage SD Card Support
OPM Wavelengths 850 / 1270 / 1300 / 1310 / 1490 / 1550 / 1577 / 1625 / 1650nm
OPM Measurement Range -50 to +26dBm
VFL Output ≥10mW
VFL Detection Range >10km
OLS Wavelengths 1310 / 1550nm
OLS Modulation Modes CW / 270Hz / 330Hz / 1kHz / 2kHz
Optical Connectors Universal FC / SC / ST
Included Optical Adapters Swappable SC & FC adapter heads
RJ45 Functions Line Sequence / Cable Length / Wire Tracking
Display 3.5-inch HD Multi-Touch Colour LCD
Battery 4000mAh / 3.7V Lithium Battery
Charging Interface Type-C
Operating Temperature -10°C to +50°C
Operating Humidity 0–90% RH, non-condensing
Dimensions 173 × 80 × 38mm
Weight Approx. 360g including battery
Hardware & Interface Highlights
3.5-inch HD multi-touch colour touchscreen
OTDR / Optical Light Source port
Optical Power Meter port
VFL port
RJ45 network testing port
Type-C USB/data and charging interface
TF/SD card expansion slot
Built-in LED flashlight
Swappable optical interface heads
RJ45 remote module stored in rear push-to-eject compartment
Directional navigation controls
OK / Menu / Analysis / Setup / ESC / Power controls
What’s in the Box
1 × COMPTYCO KP600 UPC OTDR Fibre Optic Tester
1 × Factory Testing Report
1 × User Manual / Guide
1 × Power Adapter / Charging Head
1 × Type-C Data & Charging Cable
1 × SC Interchangeable Adapter Head
1 × FC Interchangeable Adapter Head – Pre-installed
1 × RJ45 Wire Tracker Receiver Probe
1 × RJ45 Remote Adapter Module – Pre-installed in host compartment
1 × Protective Carrying Bag
1 × Packaging Box

Package Dimensions: Approx. 24.1 × 10.6 × 7.7cm
Total Package Weight: Approx. 730g
